PCB Capabilities


Number of Layers
1 layer
2 layers

Material
FR-4

Board Thickness (mm)
0.5, 0.8, 1.0, 1.6, 2.4

Copper weight (oz/sq ft)
pre-plate
1 oz

PCB Size(Dimension)
Maximum
12x24 in2
Minimum
5x8 in2

Track
Min clearances
10 mil
Min track to track
10 mil
Min pad to pad
10 mil
Min track to Rout
20 mil
Min track width
10 mil
Min track to edge
20 mil

Drill Sizes (CNC)
Min hole size
0.5 mm
Max hole size
6.0 mm
Radial Variation
0.3 mm

Polygon plane (Hatch)
Track width
8 mil
Grid width
7 mil
Air gap width
20 mil

Silkscreen
Minimum Character Width (Legend)
12 mil
Minimum Character Height (Legend)
40 mil

Silkscreen Color
Black
White

Solder Mask Color
Green
Black
Red
White

Surface Finishing
Flux Cloating
Lead-free HAL
Immersion Gold
Nickel Clothing

Capacity
10,000 ft2  /month
